Dimensions of material beyond the nanoscale (100 nm) range.
Most frequent 0D nanomaterials.
Contains nanorods, nanotubes, and nanowires.

Nanoparticles Specification and Details

A nanoparticle is a tiny particle that goes from 1 to 100 nanometers. The name nanoparticle is a combination of the Greek terms nanosî (dwarf) and particulumî (particle) (Latin: particle). Nano refers to a particular order of magnitude, 10-9 the metric system. It refers to a volume, weight, or time measure, with a nanometer (nm = 10-9 meters) equaling one billionth of a meter. It is usually in powder form; hence, it is called Nanopowder. Nanoparticles invisible to the naked eye can have different chemical and physical characteristics than their bigger material counterparts. At least most of the Nanopowder in the total volume fraction must have a particle size of 100 nm or less. The majority of nano-particles are composed of only several hundred atoms.

Nanopowder manufactured synthetically serves a significant role in nanotechnology. They play a crucial role in nanomaterials and have a variety of applications. It comprises dispersions in gases (e.g., aerosols), ultrafine powder for thin films, fluids (dispersed, for example, ferrofluids), and solid bodies (nanocomposites). The method of integrating nano-particles into most nanocomposite materials is complicated. Nanoparticles are infamous for agglomeration, creating massive clusters that are hard to retrieve. Furthermore, when researchers use Nanopowder as a composite material, they may not necessarily preserve their particular size-related features.

Dimensional Classification of Nanoparticles

• The classification takes place on the number of dimensions of material beyond the nanoscale (100 nm) range.
• The measurement of all dimensions of zero-dimensional (0D) nanomaterials happens on the nanoscale. These are the most frequent 0D nanomaterials.
• One dimension in one-dimensional nanomaterials (1D) is outside the nanoscale. This category contains nanorods, nanotubes, and nanowires.
• Two dimensions are beyond the nanoscale in two-dimensional nanomaterials (2D). This class comprises graphene, nanofilms, nanolayers, and nanocoating’s, which all have plate-like forms.
• Three-dimensional nanomaterials (3D) are nanomaterials that do not have any dimensions confined to the nanoscale. This class includes bulk powders, nanoparticle dispersions, nanowire and nanotube bundles, and multi-nanolayers.


Nanopowder varies depending on sizes, shapes, and physical and chemical characteristics. There are various types, such as Carbon-based Nanopowder, ceramic Nanopowder, metal Nanopowder, semiconductor Nanopowder, polymeric, and lipid-based nano particles.

Carbon Nanoparticles

Carbon nanotubes (CNTs) and fullerenes are the two primary materials in carbon-based nanoparticles. CNTs are just graphene sheets folded into tubes. As they are almost 100 times stronger than steel, these materials are advantageous for structural reinforcement. CNTs have two major types – single-walled carbon nanotubes (SWCNTs) and multi-walled carbon nanotubes (MWCNTs). CNTs are one-of-a-kind as they are heat resistant along their length but non-conductive across their width.

Metal Nanoparticles

Metal precursors are promising for creating metal nanoparticles. Chemical, electrochemical, or photochemical processes can create this Nanopowder. Metal Nanopowder is created chemically by reducing metal-ion precursors in solution using chemical reducing agents. These have high surface energy and the capacity to adsorb tiny molecules. These Nanopowder have applications in research, biomolecule detection and imaging, and ecological and bioanalytical applications. For example, gold nano particles perfectly coat the sample before SEM analysis. It improves the electrical stream, which allows us to obtain high-quality SEM photos. Examples of metal Nanopowder are Aluminium Oxide Nanopowder, Zinc Oxide Nanopowder, and Iron Oxide Nanopowder.

Ceramic Nanoparticles

Ceramic nanoparticles are solids composed of oxides, carbides, carbonates, and phosphates. These Nanopowder are extremely heat resistant and chemically inert. Ceramic Nanopowder acts as an excellent drug delivery agent by manipulating several properties such as size, size distribution, porosity, the surface volume ratio, and many more. It also helps in photocatalysis, dye photodegradation, medication delivery, and imaging. These Nanopowder have been successful as medication delivery methods for many disorders such as bacterial infections, glaucoma, cancer, etc. An example of ceramic Nanopowder is Magnesium Oxide Nanopowder.

Lipid Nanoparticles

Lipid nanoparticles are spherical in shape and range in diameter from 10 to 100nm. Surfactants and emulsifiers stabilize the exterior body of these nano particles. It has a lipid-based solid core and a matrix comprising soluble lipophilic molecules.

Polymeric Nanoparticles

Polymeric nanoparticles consist of organic materials. Its shape resembles nano-capsular or nano-spheres, depending on the production technique. A matrix-like structure characterizes a nano-sphere particle, whereas a core-shell morphology characterizes a nano-capsular particle.

Nanoparticles Properties

Compared to the same material in bulk, such as powders, lumps, or sheets, Nanopowder holds an extraordinarily significant surface area to volume ratio. The bigger the surface area to volume ratio of a solid, the smaller its particles. When the length of a cube’s side decreases by ten times, the surface area to volume ratio increases by ten times.
The electrical, optical, and chemical characteristics of Nanopowder may differ significantly from the bulk components. Materials act extremely differently at the nanoscale than at larger sizes, and it is difficult to anticipate the physical and chemical properties of particles of such a small size.

Aerosols (solids or liquids in the air), suspensions (solids in liquids), and emulsions can all contain nano-particles (liquids in liquids). The characteristics of nano particles are affected by the presence of particular substances.

The characteristics of materials at nanoparticle size change substantially from their bulk state due to an increase in the relative surface area and quantum size changes. These variables can alter or improve attributes like reactivity, strength, and electrical properties. When the nanoscale size range is reached, it becomes dominating. The quantum size factor influences the physics of electron characteristics in materials with significant particle size reductions. Jumping from macro to micro scales does not influence this effect.

Nanoparticles Applications

Controlled release, drug molecule protection, the potential to combine treatment with imaging, selective targeting, and many more advantages are among the benefits of polymeric nano particles. Polymeric nanoparticles used in medication delivery are biodegradable and biocompatible.

Nanomaterials use in a broad range of sectors, from healthcare and cosmetology to environmental conservation and air purification, due to their capacity to manufacture materials precisely to perform a particular purpose. The Healthcare industry employs Nanopowder in various applications, one of which is medication delivery.

For example, Nanopowder delivers chemotherapy treatments directly to tumour formation, providing drugs to damaged artery regions to combat cardiovascular disease.
Researchers are studying Carbon nanotubes for use in procedures such as adding antibodies to nanotubes to make bacteria sensors.

Mineral Nanopowder, such as titanium oxide, is utilized in sunscreen in the cosmetics sector due to the poor long-term durability of conventional chemical UV protection. Like the bulk substance, titanium oxide Nanopowder can enhance UV protection while reducing the visually unattractive whitening inherent with skincare products in their nano-form.
Carbon nanotubes aid in the evolution of aircraft wings in aerospace. The nanotubes are employed in a composite form to fold in response to an electric voltage application.
Another use of nano-particles in this area is antimicrobial nanotechnology in goods such as sports towels and mats to avoid bacteria-related diseases.

Nanomaterials are applicable for military use. One such example is the employment of movable pigment nanoparticles to provide a better type of camouflage by injecting the nano particles into the material of troops’ uniforms. Furthermore, the military has developed sensor systems that detect biological pathogens utilizing nanomaterials such as titanium dioxide.

How to manufacture it?

Any solid or liquid substance, including metals, dielectrics, and semiconductors, may be used to create synthetic nanoparticles. It might be homogenous or heterogeneous internally. Gas condensation, attrition, chemical precipitation, ion implantation, pyrolysis, hydrothermal synthesis, and biosynthesis are all processes for producing nanoparticles.


Any solid or liquid substance, including metals, dielectrics, and semiconductors, may be used to create synthetic Nanopowder. It might be homogenous or heterogeneous internally. Gas condensation, attrition, chemical precipitation, ion implantation, pyrolysis, hydrothermal synthesis, and biosynthesis are all processes for producing Nanopowder.


Friable macro- or micro-scale can grind solid particles in a ball mill, planetary ball mill, or other size-reducing devices until they are sufficiently small to be in the nanoscale size range. The resultant powder can be air categorized by removing the nano particles.

Biopolymer degradation

Biopolymers such as cellulose, lignin, chitin, and starch can break down into individual nanoscale essential components, which ultimately produce anisotropic nano-particles. Mechanical disintegration is used with chemical oxidation to break down the biopolymers.


Another way of manufacturing nano particles is to use combustion or pyrolysis to convert a suitable precursor ingredient, such as a gas (e.g., methane) or aerosol, into solid particles. Instead of single particles, traditional pyrolysis frequently produces aggregates and agglomerates. The method can overcome it by using ultrasonic nozzles spray pyrolysis, which forces the precursor liquid through an opening at high pressure.


Many features of nano-particles, including durability, absorption, and biological or chemical activity, may be significantly changed by encapsulating them with various compounds, a process known as functionalization. Functionalized nanomaterial-based catalysts can catalyze many known organic processes. The surface coating should be opposite to provide excellent water solubility and minimize nanoparticle aggregation in biological applications.
Highly charged coatings increase non-specific binding in serum or on the cell surface, whereas polyethylene glycol coupled to final hydroxyl or methoxy groups repels non-specific interactions.

Safety Measures

Nanoparticles have potential medical and environmental risks. The impacts of Zinc oxide Nanopowder on human immune cells have revealed various degrees of cytotoxicity. The majority of these are results of the particles’ high surface-to-volume ratio making them highly reactive or catalytic. Therefore, following the safety measures is crucial.
• Wash lab coats regularly.
• Arm sleeves are essential when researchers expect high levels of exposure or splashes of nanoparticle-containing liquids.
• All labs must have hand-washing facilities. Wash hands after handling nanomaterials.
• When working in any lab, standard safety glasses are necessary.
• When working with nanomaterials, use disposable nitrile gloves.
• Wear Long trousers and closed-toed shoes.
• To avoid inhalation, respirators and ventilation systems are necessary.
• Handle dry Nanopowder in a desiccator, biological safety container, glove box, or filtered vented enclosure.
• Dispose of dry Nanopowder in sealed containers.
